DeltaV Lab

SYS.STATUS: Browser sandbox with real integrators — not flight-certified software

DeltaV Lab is my open-source attempt to sit between Kerbal Space Program and proprietary trajectory tools: build a staged rocket in a Vehicle Assembly Building (VAB), launch it, watch telemetry update, and trust that the outcome came from integration — not a scripted success screen.

The repo README calls it “engineering-grade.” I wrote that README. This project page is the honest counterweight: it is a serious teaching sandbox, not something I would hand to a range-safety officer without a validation program I have not built yet.

What it is (scope)

DeltaV Lab splits into two primary experiences, matching the repo structure:

Under the hood, physics runs in a Web Worker at a fixed 50 Hz timestep (FIXED_DT = 0.02 s in PhysicsWorker.ts). State sync uses SharedArrayBuffer so the main thread paints without blocking integration.

Beyond raw flight, the repo ships instructor and ops tooling I rarely see in browser demos:

• DSL flight computer — WHEN <condition> THEN <action> scripts for pitch, throttle, staging, SAS modes
• Pre-launch checklist (C) — Go/No-Go validation panel
• Flight Termination System (T) — FTS arm/disarm interlock
• Fault injector (Ctrl+I) — engine flameouts, sensor glitches, fuel leaks for classroom scenarios
• Black box + CSV export (R / E) — high-frequency telemetry recording for post-flight analysis
• Analysis view (analysis.html) — parse exported flight data

Full keyboard map: simulation_controls.md in the repo.

Who I built it for

• Students and hobbyists who want KSP-style experimentation with math they can audit
• Myself when I need to sanity-check staging logic, Tsiolkovsky budgets, or guidance scripts without STK licensing
• Anyone curious about how browser threading, deterministic integrators, and flight-software-shaped tooling fit together

It is not aimed at replacing GMAT, FreeFlyer, or internal corporate dispersion analysis — and I wrote a whole transmission about why.

Physics snapshot (accurate, not marketing)

The simulation is 2D with inverse-square gravity, exponential atmosphere (scale height 7 km, density LUT up to 200 km), altitude-varying wind layers, simplified Dryden gusts, drag from dynamic pressure, thrust from variable mass with sea-level/vacuum Isp, thermal ablation on re-entry, and CP-vs-CoM aerodynamic stability checks.

Integration is RK4 at 50 Hz in the worker. Orbital elements use Vis-Viva and Keplerian math; orbit prediction reuses the same RK4 core.

That is real physics work. It is also not 6DOF attitude dynamics, NRLMSISE-00 atmospheres, or Monte Carlo dispersion. The gap is intentional honesty, not false modesty — see the limitations transmission.

Fuckups & learnings

• Worker communication is protocol design. Early versions spammed postMessage with chatty per-frame coordinates. Moving to SharedArrayBuffer and batched state snapshots fixed the stutter.
• README hype vs. repo reality. Calling it “hyper-realistic” in marketing copy while path_to_perfection.md lists 16 missing professional features taught me to split implemented rigor from industry trust requirements.
• 2D is a feature and a ceiling. It keeps the integrator teachable. It also means roll, yaw coupling, and slosh are out of scope until I do a quaternion rewrite I have not shipped.

Deep-dive transmissions

Read these in order if you want the full story:

1. Why DeltaV Lab exists and what it actually is — motivation, audience, VAB + Mission Control scope, repo link
2. The science inside DeltaV Lab — RK4, forces, atmosphere, Tsiolkovsky, DSL, worker architecture (sourced from the sim repo)
3. Why it is not professional-grade — no published flight V&V, simplified environments, browser limits, gaps from path_to_perfection.md
4. What is next — roadmap to professional-grade — trust ladder, phased V&V/Monte Carlo/HIL plan, commercial requirements
5. Native physics core migration — React/TS UI stays; Rust/C++/Python owns integration and batch runs

Supporting logs:

• RK4, Web Workers, and the worker-protocol fuckup — engineering diary focused on threading, not duplicated physics lectures
• Flight computer DSL: teaching autopilot without faking physics — the WHEN/THEN guidance language
• DeltaV Lab Scrollytelling Demo — live Scrollytell component walkthrough with synced launch telemetry

Run it locally

git clone https://github.com/dhaatrik/professional-rocket-launch-simulation.git
cd professional-rocket-launch-simulation
npm install
npm run dev
# Open http://localhost:8080 — optional second screen at /telemetry.html

Tests: npm run test (Vitest). CI runs on every push.

Closing transmission

Pull the repo. Break my drag model. Tell me where the 2D assumptions lie. That is the point — dull truth over gorgeous lies.

If you want the threading war stories, start with the mission log. If you want the physics derivations, read the science transmission. If you want the uncomfortable “would I bet a real launch on this?” answer, that is the limitations post.
